Virtual Network configuration
A31003-W1040-U101-1-7619, July 2006 DRAFT
158 HiPath Wireless Controller, Access Points and Convergence Software V4.0, C10/C100/C1000 User Guide
hwc_vnsconfiguration.fm
Configuring filtering rules for a VNS
● Select IP/Port.
● Type the default gateway IP address that you defined in the Topology tab for this VNS.
7. Click Add. The information appears in the Filter Rules area of the tab.
8. Select the new filter, then do the following:
● If applicable, select In to refer to traffic from the wireless device that is trying to get on
the network.
● If applicable, select Out to refer to traffic from the network host that is trying to get to
a wireless device.
● Select the Allow checkbox applicable to the rule you defined.
9. Edit the order of a filter by selecting the filter and clicking the Up and Down buttons. The
filtering rules are executed in the order you define here.
10. To save your changes, click Save.
7.6.2.1 Non-authenticated filter examples
A basic non-authenticated filter for internal Captive Portal should have three rules, in the
following order:
>
Administrators must ensure that the non-authenticated filter allows access to the
corresponding authentication server:
● Internal captive portal – IP address of the VNS interface
● External captive portal P – IP address of external captive portal server
In Out Allow IP / Port Description
x x x IP address of default
gateway (VNS Interface
IP)
Allow all incoming wireless devices access
to the default gateway of the VNS.
x x x IP address of the DNS
Server
Allow all incoming wireless devices access
to the DNS server of the VNS.
x x *.*.*.* Deny everything else.
Table 7 Non-authenticated filter example A
>
For external Captive Portal, an additional rule to Allow (in/out) access to the external
Captive Portal authentication/Web server is required.
