Siemens LME39.100C2 - Parameters without index, with no direct display; Example of parameter 224 (max. time until air pressure on) on the parameter level

61/73
Building Technologies Division Basic Documentation LME39… CC1P7106en
20 Operating variants of the parameters 08.12.2017
20.2 Parameters without index, with no direct
display
20.2.1 Example of parameter 224 (max. time until air
pressure on) on the parameter level
P
Vh
mi n
s%
Bild 172/1107
Press
to select specified time for air
pressure signal air pressure switch.
Display: Parameter 224: flashes, characters
._._
do not.
/
reset
or
P
Vh
mi n
s%
Bild 173/1107
Press
or to go to editing mode.
Display: 48.510
or
P
Vhmins%
Bild 174/1107
Press
or to shift the former specified
time to change mode one place to the left.
Display: Specified time 48.510 flashes.
Note!
To detect display errors, the value appears
one place shifted to the left.
or
P
Vhmins%
Bild 175/1107
Press
or to set the specified time.
Display: Specified time 53.361 flashes.
