171/213
Building Technologies Basic documentation LMV37.4... CC1P7546en
HVAC Products 26 Parameter level 01.12.2009
F
and A
and
or
P
Vhsmin%
Bild 139/080 7
Press or to change the value as
required.
Example:
00.0
F
or A
P
Vhmins%
Bild 1 40/0 707
Release
F or A .
The required value is adopted.
Example:
P5:50.0:46.0
>3 s
P
Vh
mi n
s%
Bild 124/070 7
Keep
depressed for >3 s.
CALC appears.
P
Vhmins%
7´Bild 14 1/0 707
The display jumps to
P6.
Curvepoint Value 1
fuel
Value 2
air
P5 50.0 46.0
P6 57.5 57.0
P7 65.0 68.0
P8 72.0 79.0
All curvepoints from P5 to P9 have now been
automatically recalculated (linear interpolation):
P9 80.0 90.0
>3 s
P
Vh
mi n
s%
Bild 124/070 7
Keep
depressed for >3 s.
CALC appears.
P
Vhmins%
Bild 1 42/0 707
The display jumps to
P4.
Curvepoint Value 1
fuel
Value 2
air
P5 50.0 46.0
P4 45.5 40.0
P3 41.0 35.0
P2 36.5 29.5
All curvepoints from P1 to P5 have now been
automatically recalculated (linear interpolation):
P1 32.0 24.0
