Building Technologies Basic documentation LMV37.4... CC1P7546en
HVAC Products 26 Parameter level 01.12.2009
>3 s
P
Vh
mi n
s%
Bild 124/070 7
>3 s
If it is not only the current curvepoint that shall be changed but all other curvepoints in the direction of
travel as well, a new straight line from the current curvepoint to
P9 (press ) or P1 (press ) can
be calculated by a long push on
or .
Display
CALC
Example of presentation
)
P5 down to P1
Keep
depressed for >3 s
P5 up to P9
Keep
de
p
ressed for >3 s
CALC -
CALC +
Figure 63: Changing several curvepoints
&
Note
Due to interpolation, a number of curvepoints change. To be able to make a
check on the burner itself, the changed curvepoints must be approached in
the warm settings. If these curvepoints have not yet been completely ap-
proached, OFF UPR appears on the normal display of the AZL2…
