7ML19985CN01 Milltronics SF 500 – INSTRUCTION MANUAL Page 39
mmmmm
Recalibration
Programming
Access P365 and enter EDIT mode
Span 1 will have already been set as part of the Start Up and initial calibration. Therefore,
select 2.
Access P017 and enter EDIT mode
Enter the test rate value, and press to do a span calibration.
To do a span calibration for another condition, (i.e. span 3 or 4 etc.), access P365 and
repeat these steps for each condition. As with any initial span, follow the span calibration
for each multispan with a material test and factoring.
To use remote span selection, auxiliary inputs, 1 and/or 2 or 3, are programmed to read
the contact state as the span selection. Remote selection overrides the keypad (or
Dolphin Plus) selection. The auxiliary inputs override the keypad selection.
Access P270 and enter EDIT mode
Enter . This programs auxiliary Input 1 (terminal 24) to read the contact state for span
selections: 1 or 2.
Access P270 and enter EDIT mode (when using spans 3 and/or 4)
Enter . This programs auxiliary Input 2 (terminal 25), in conjunction with auxiliary
input 1 to read the contact state for span selections 3 and 4.
Access P270 and enter EDIT mode (when using spans 5 to 8)
Enter . This programs auxiliary input 3 (terminal 26), in conjunction with auxiliary
input 1 and auxiliary input 2 to read the contact state for span selections 5 to 8.
P365 Multispan E
Select [1-8] 0
P017 Test Rate: Weight MS2 E
Enter Test Rate 0
P270-01 auxiliary Input Function E
Select Function [0-13] 0
P270-02 auxiliary Input Function E
Select Function [0-13] 0
P270-03 auxiliary Input Function E
Select Function [0-13] 0
