Page 40 Milltronics SF 500 – INSTRUCTION MANUAL 7ML19985CN01
mmmmm
Recalibration
Remote selection of a span is not enabled until a span calibration has been done. Initial
span selection must be done via the Multispan parameter, P365.
Operation
When span calibration is done, press to revert to the RUN mode.
When the material to be run changes, the multispan is changed to the corresponding
span. This is completed either by changing the span value entered in P365, or by closing
the appropriate contacts connected to the programmed auxiliary inputs.
If required, reset or note the totalizer value, as the process materials being conveyed may
change. Refer to
Totalization (P619-P648)
on page 111.
Linearization applies concurrently to spans.
Rate kg/h 0.00 kg/h MS2
Total 1: 0.00 kg
Span
auxiliary Input
Aux 1
Multispan
Selection Aux 2
Multispan
Selection
Aux 3
1
2
3
4
5
6
7
8
e.g. if there is no material flowing, the
current rate is 0 and no material has been
totalized.
