Functional description
MOBILETT
SPR8-230.621.01.03.02 23
of 106
X-ray Tube Assembly with Multi-leaf Colli-
mator
(1) Handle
(2) Measuring tape
(3) Adjustment knobs for the collimator
(4) Slots for additional filters and DAP Ionization chamber (Option)
(5) Angle gauge
SCALE INDEX
MOB00382
(1)
(2)
(3)
(4)
(5)
