Technical Data
MOBILETT
SPR8-230.621.01.03.02 83
of 106
Parts subject to wear
For further information,
(→ see service instructions)
Hand/Emergency brake ❏ The brake linings at the wheels.
❏ The braking wire between the hand brake and the braking arm.
Arm system friction
linings
❏ The friction lining for lower arm, placed at lower link.
❏ The friction lining for upper arm, placed at the counter acting rollers at the
spring pack.
Fork friction linings ❏ The friction for the single tank movement (2), placed at the ends of the fork.
Power cable, power plug ❏ The power cable between the power plug and the unit.
Cable winder ❏ Complete cable winder, containing of the power cable and the cable winder.
Exposure cord ❏ The coiled cord between the detachable IR remote control and the unit.
Collimator lamp ❏ The halogen lamp inside the collimator which is used to indicate the size of
the X-ray field.
Backup battery ❏ The battery, placed on circuit board D916, which supplies the memory
circuits with power.
Transmission belts ❏ Transmission from the motor to the rear wheels, for MOBILETT XP Hybrid
only.
Power batteries ❏ 24 maintenance free sealed lead-acid batteries. Approximately 1 - 2 years
lifetime at normal use, for MOBILETT XP Hybrid only
IR remote control battery,
option
❏ The battery, placed in the battery compartment.
