Functional description
Operator Manual
SPR8-230.621.01.03.02
26 of 106
Equipotential bonding
The MOBILETT can be connected to a Protective Earth Terminal with the potential
equalizer connector found next to the transport safeguard. This will ensure that
the MOBILETT has the same electrical potential as other units connected to the
same Protective Earth Terminal.
Arm system
The MOBILETT is provided with a counterbalanced, double articulated arm
system. The X-ray tube assembly and the arm system remain in position without
any additional locks.
Hand/Parking brake
(1) Hand/Parking brake
(1)
MOB00284
