Functional description

MOBILETT

SPR8-230.621.01.03.02 27

of 106

Accessories and options

The following accessories and options are available:

Name Material No. Manufacturer

Options:

DAP measuring system 839 1919 Siemens

Remote control 839 1927 Siemens

Accessories:

Pediatric filter 2.4 mm 0971 4981 Siemens

Pediatric filter 4.3 mm 0971 4999 Siemens

Angle gauge 90240 19 Siemens
