Siemens MOBILETT XP User Manual

Technical Data
Operator Manual
SPR8-230.621.01.03.02
80 of 106
X-Ray Tube
Stabilization: Microprocessor-based adjustment and regulation during exposure
X-ray tube: Siemens P135/30 R with nominal focal spot value 0.8 (acc. to IEC 60336)
Anode rotation: 8 500 r.p.m., 142 Hz (anode angle 15°)
Anode heat storage
capacity:
90 000 J = 122 000 HU
Tube housing heat storage
capacity:
800 000 J = 1 100 000 HU
Inherent filtration
- Collimator:
- Tube housing assembly:
- Totally:
min. 1.6 mm Al (at 70 kVp)
min. 1.5 mm Al (at 70 kVp)
min. 3.1 mm Al according to IEC 60 522
Collimator: Manually-adjustable multi-leaf collimator, rotatable ±90°
Collimator light and light
field intensity:
Halogen lamp min. 180 lux at 1 m SID
Tube housing assembly: Maximum temperature 60°C, maximum 2000 mAs/h, nominal continuous
rating 75 W until the covers reach 60°C
Leakage technique
factors
1
1
The leakage radiation of the tube housing assembly and attached collimator complies to the requirement of 21 CFR part 1020.3 (K) and
IEC60601-1-3. For further informations see data sheet X-ray tube.
133 kVp/10 mAs, 200 exposures/h
