Operation
Operator Manual
SPR8-230.621.01.03.02
48 of 106
Exposure
The remote control is used in two-step.
◆ Press the exposure release switch once.
– The preparation cycle is activated.
– The green “ Ready” lamp goes out and does not light up again until anode
rotation has reached full speed (after approx. 2.5 s). This is indicated by three
short “ beeps”. The generator is now ready for exposure release.
◆ To release the exposure, press the exposure release switch a second time,
and hold it down until the exposure is terminated.
– The amber exposure indicator lights during the exposure. The indication
lasts somewhat longer than the actual exposure, in order to make the
operator aware of very short exposures.
– A longer beep indicates the end of the exposure.
– After the exposure is completed, both the X-ray unit and remote control will
automatically return to stand-by mode.
Finishing operation
◆ Return the remote control back to the remote holder on the X-ray unit.
If exposure is not released within 15 s the preparation will automatically be inter-
rupted and display message ERR 25 appears.
If the remote control is not returned to the remote holder within three minutes
after use, the remote finder feature will activate causing the remote control to
beep. The beeps will continue indefinitely until the remote control is located and
put back in the remote holder.
The remote finder feature is not implemented in the spare remote control,
included in the delivery.
