Siemens POLYMOBIL III - Prerequisites; Specially Marked Text; Documents Required; Tools and Measuring Instruments Required

1 - 1
Siemens AG RXB8-115.061.02 Page 1 of 4 POLYMOBIL III
Medical Solutions Rev. 01 10.95 CS PS 24
Prerequisites 1
Specially marked text 1
Documents required 1
Tools and measuring instruments required 1
All texts marked with "Warning" contain information regarding
potential hazards to health or life.
All texts marked "Caution!" contain information regarding poten-
tial hazards and steps to be taken to avoid hazards.
All texts marked "Note:" contain additional information regarding
the following procedure step. It is intended to clarify the step or to
indicate ways to avoid predictable problems.
• Wiring diagram X038I
• Description of functions RXB8-115.041.02...
• Usual service tools
• Digital multimeter:
Fluke 8060 A 97 02 101 Y4290
• 2 channel storage oscilloscope:
Tektronik Type 2232 97 02 234 Y3155
• mAs meter 81 60 400 RE999
• Protective ground wire and leakage current
tester: BENDER safety tester 97 06 979 Y0526
• Radiation detector
See SPEED INFO 93/91
96 60 754 RE999
During oscilloscope operation the protective ground wire connec-
tion in the power cable must not be interrupted under any circum-
stances.
For measurements where ground loops that may be present could
impair the measuring result, use the TEK amplifier and the trigger
attachment.
WARNING
CAUTION
NOTE
CAUTION
