Siemens SC 7000 Service Manual

Service Manual SC 7000 and SC 9000XL Patient Monitors
118 Siemens Medical Systems, EM-PCS, Danvers ASK-T898-03-7600
NOT A CONTROLLED DOCUMENT
7k9kXLSM.apc.CD_ROM.fm/04-99/kaupp
80117xxx
80118xxx
Serial Interface to Remote Keypad -
related
Try disconnecting/
reconnecting keypad.
If problem persists, swap
cable with known-good
keypad.
If problem persists, replace
Main Processor Board
Subassembly.
80119xxx
8011axxx
Temperature - related (MultiMed Pod) Try disconnecting/
reconnecting cable.
If problem persists, swap
cable with known-good
cable.
If problem persists try
swapping pod.
If problem persists, replace
Main Processor Board
Subassembly.
80127xxx
80128xxx
bkg_operational determined
MONITORING SW is corrupt.
Background entity
determined that the
Main Software was
corrupted (BAD
CRC)
Try upgrading SW to
currently released version.
If error persists, replace
Main Processor Board
Subassembly.
80129014 boot_program_CPS_images failed with
status: A on 68302 image.
CPS or IDS flash
memory could not be
programmed with
new software
Re-download CPS/IDS
software. If problem persists
replace CPS or IDS.
8012901e boot_validate_download_card could not
open/close one of the boot files.
Software memory
card may have been
removed during a
download or the card
may have become
corrupted
Re-download monitor
software. If problem persists,
replace memory card.
8014bxxx
8014cxxx
RECORDINGS - related Try disconnecting/
reconnecting cable.
If problem persists, swap
cable with known-good
cable.
If problem persists try
swapping Recorder.
If problem persists, replace
Main Processor Board
Subassembly.
Table C-1Diagnostic Log Codes (Continued)
Code
xxx = any
alphanumeric
characters
Description Cause Action
