Siemens SC 7000 Service Manual

Service Manual SC 7000 and SC 9000XL Patient Monitors
124 Siemens Medical Systems, EM-PCS, Danvers ASK-T898-03-7600
NOT A CONTROLLED DOCUMENT
7k9kXLSM.apc.CD_ROM.fm/04-99/kaupp
80255xxx
80256xxx
Try upgrading SW to
currently released version.
If error persists, replace
Main Processor Board
Subassembly.
8025bxxx
8025cxxx
80263xxx
80264xxx
RS-232 Output - related Ignore.
If problem persists, upgrade
SW to ≥VC2.x.
If problem persists, replace
Main Processor Board
Subassembly.
80264001 Invalid status after RX_RESET!
rx_data=A
Recorder ASIC failed
hardware test
Power cycle unit. If error
persists, replace Main
Processor Board
Subassembly.
80264002 TX Empty should be set after
TX_RESET! tx_data=A
Recorder ASIC failed
cold start test
Power cycle unit. If error
persists, replace Main
Processor Board
Subassembly.
8026dxxx
8026exxx
Network Communications - related Try disconnecting/
reconnecting cable(s)
between Monitor and
network wallbox.
Verify proper SW version(s)
installed in all related
devices, in accordance with
SW compatibility chart for
Monitor SW.
If problem persists, try
swapping CPS/IDS with
known-good device.
If problem persists, replace
Main Processor Board
Subassembly.
Table C-1Diagnostic Log Codes (Continued)
Code
xxx = any
alphanumeric
characters
Description Cause Action
