Siemens SC 7000 Service Manual

Service Manual SC 7000 and SC 9000XL Patient Monitors
126 Siemens Medical Systems, EM-PCS, Danvers ASK-T898-03-7600
NOT A CONTROLLED DOCUMENT
7k9kXLSM.apc.CD_ROM.fm/04-99/kaupp
80281xxx
80282xxx
80283xxx
80284xxx
HEMOPOD / HEMOMED - related Try disconnecting/
reconnecting cable.
If problem persists, swap
cable with known-good
cable.
If problem persists try
swapping pod.
If problem persists, replace
Main Processor Board
Subassembly.
80289xxx
8028axxx
80291xxx
80292xxx
Pod communications
problem.
Pod cable, Pod, or
CPU board failed
Try disconnecting/
reconnecting cable.
If problem persists, swap
cable with known-good
cable.
If problem persists try
swapping pod.
If problem persists, replace
Main Processor Board
Subassembly.
8029fxxx
802a0xxx
802a1xxx
802a2xxx
Power -related Replace Battery
Replace Main Processor
Board Subassembly.
802a3xxx
802a4xxx
QRS Sync pulse - related Try disconnecting/
reconnecting cable.
If problem persists, swap
cable with known-good
cable.
If problem persists try
swapping pod.
If problem persists, replace
Main Processor Board
Subassembly.
802a5001 ERROR: Address: A Written:B Read:D
Mask:D (E F)
RAM test failed over
TAXI in either CPS/
IDS or Monitor ;
Address of failure
given in msg
Isolate problem to CPS/IDS
or Monitor. If monitor then
replace Main Processor
Board Subassembly; If CPS
or IDS, replace CPS or IDS.
Table C-1Diagnostic Log Codes (Continued)
