Siemens SC 7000 Service Manual

Service Manual SC 7000 and SC 9000XL Patient Monitors
132 Siemens Medical Systems, EM-PCS, Danvers ASK-T898-03-7600
NOT A CONTROLLED DOCUMENT
7k9kXLSM.apc.CD_ROM.fm/04-99/kaupp
803a1xxx
803a2xxx
12 LEAD POD - related Try disconnecting/
reconnecting cable.
If problem persists, swap
cable with known-good
cable.
If problem persists try
swapping pod.
If problem persists, replace
Main Processor Board
Subassembly.
803a3xxx
803a4xxx
Serial Interface to Remote Keypad -
related
Try disconnecting/
reconnecting keypad.
If problem persists, swap
cable with known-good
keypad.
If problem persists, replace
Main Processor Board
Subassembly.
8033b006 Remote View Display
Reset with Wedge
Upgrade SW to ≥VC2.x.
803e5xxx
803e6xxx
803e7xxx
803e8xxx
SPO2 - related Try disconnecting/
reconnecting cable.
If problem persists, try
replacing sensor.
If problem persists, swap
cable with known-good
cable.
If problem persists try
swapping pod.
If problem persists, replace
Main Processor Board
Subassembly.
8035900b IMRP Shutdown Timed Out! ROM table on CPS or
IDS is corrupt
Reinstall the software on
CPS or IDS
80361xxx
80362xxx
12 LEAD POD - related Try disconnecting/
reconnecting cable.
If problem persists, swap
cable with known-good
cable.
If problem persists try
swapping pod.
If problem persists, replace
Main Processor Board
Subassembly.
Table C-1Diagnostic Log Codes (Continued)
Code
xxx = any
alphanumeric
characters
Description Cause Action
