Description of the device
3.2 Product properties
SCALANCE X-100
Operating Instructions, 12/2016, A2B00060666-08
17
3.2.4
SCALANCE X108PoE
Possible connections
The SCALANCE X108 PoE has eight RJ-45 jacks for the connection of end devices or other
network segments. Ports 1 and 2 have the PoE function.
Figure 3-4 SCALANCE X108PoE
Power over Ethernet (PoE) function
The PoE function allows the power supply of connected Ethernet devices via the Ethernet
cable so that the end device does not need a separate power supply.
Per PoE port of the PSE (Power Sourcing Equipment), a maximum of 15.4 W power are
available according to the 802.3af standard.
Note
With a 100 m long cable connected, the end device then has a maximum of 12.95 W
available.
You will find more information on the PoE function in the section "TP ports (Page 20)".
