Description of the device
3.2 Product properties
SCALANCE X-100
18 Operating Instructions, 12/2016, A2B00060666-08
SCALANCE X112-2
Possible connections
The SCALANCE X112-2 has twelve RJ-45 jacks and two BFOC sockets for the connection
of end devices or other network segments.
Note
The BFOC socket (Bayonet Fiber Optic Connector) corresponds to the ST socket.
Figure 3-5 SCALANCE X112-2
