Technical specifications
7
7.1
SCALANCE X104-2
Table 7- 1 Technical specifications of the SCALANCE X104-2
Technical specifications
Order number
SCALANCE X104-2 6GK5104-2BB00-2AA3
Connection to Industrial Ethernet
Number 4
Design
RJ-45 jacks with MDI-X pinning
Properties
Half / full duplex
Transmission speed
10/100 Mbps
Optical connectors
Number
2
Design
BFOC sockets
Properties
Full duplex to 100 Base-FX
Transmission speed
100 Mbps
Permitted cable lengths (Industrial
Ethernet)
Alternative combinations per length range
0 to 55 m
• Max. 55 m IE TP Torsion Cable with IE FC RJ45 Plug 180
• Max. 45 m IE TP Torsion Cable with IE FC RJ45 + 10 m TP Cord via
IE FC RJ45 Outlet
0 to 85 m
• Max. 85 m IE FC TP Marine/Trailing Cable with IE FC RJ45 Plug 180
• Max. 75 m IE FC TP Marine/Trailing Cable + 10 m TP Cord via
IE FC RJ45 Outlet
0 to 100 m
• Max. 100 m IE FC TP Standard Cable with IE FC RJ45 Plug 180
• Max. 90 m IE FC TP Standard Cable + 10 m TP Cord via IE FC RJ45 Outlet
Optical parameters
Cable type
Multimode glass FO cable, cable cross sections 62.5/125 μm and 50/125 μm
Permitted cable length (glass FO
cable)
Cable cross-section
Permitted cable length
• 62.5/125 μm
• 50/125 μm
• 0 to 4000 m
• 0 to 5000 m
Attenuation ≤ 1 dB/km at 1300 nm
1200 MHz x km at 1300 nm
6 dB max. permitted FO cable attenuation with
3 dB link power margin
