Assembly
4.5 Wall mounting
SCALANCE X-100
Operating Instructions, 12/2016, A2B00060666-08
33
Note
Depending on the mounting surface, use suitable fittings.
Note
The wall mounting must be capable of supporting at least four times the weight of the device.
To mount the device on a wall, follow the steps below:
1. Prepare the drill holes for wall mounting. For the precise dimensions, refer to the section
"Dimension drawings (Page 69)".
2. Screw the device to the wall using the keyhole hang-up mechanisms.
3. Fit the connectors for the power supply, see the section "Power supply (Page 37)".
4. Fit the connectors for the signaling contact, refer to the section ""Signaling contacts
(Page 38)".
