Siemens SCALANCE X-100 User Manual

Technical specifications
7.3 SCALANCE X108
SCALANCE X-100
48 Operating Instructions, 12/2016, A2B00060666-08
7.3
SCALANCE X108
Table 7- 3 Technical specifications of the SCALANCE X108
Technical specifications
Order number
SCALANCE X108
6GK5108-0BA00-2AA3
Connection to Industrial Ethernet
Number
8
Design
RJ-45 jacks with MDI-X pinning
Properties
Half / full duplex
Transmission speed
10/100 Mbps
Permitted cable lengths (Industrial
Ethernet)
Alternative combinations per length range
0 to 55 m
• Max. 55 m IE TP Torsion Cable with IE FC RJ45 Plug 180
• Max. 45 m IE TP Torsion Cable with IE FC RJ45 + 10 m TP Cord via
IE FC RJ45 Outlet
0 to 85 m
• Max. 85 m IE FC TP Marine/Trailing Cable with IE FC RJ45 Plug 180
• Max. 75 m IE FC TP Marine/Trailing Cable + 10 m TP Cord via
IE FC RJ45 Outlet
0 to 100 m
• Max. 100 m IE FC TP Standard Cable with IE FC RJ45 Plug 180
• Max. 90 m IE FC TP Standard Cable + 10 m TP Cord via IE FC RJ45 Outlet
Electrical data
Power supply Voltage range 18 to 32 VDC Safe Extra Low Voltage
(SELV)
Rated voltage
24 VDC
Design
4-terminal plug-in block
Signaling contact
Current
max. 100 mA
Rated voltage
24 VDC
Design
2-pin plug-in terminal block
Current consumption
Typical
140 mA
Power loss at 24 VDC
Typical
3.36 W
Overvoltage protection at input
PTC resettable fuse (0.6 A / 60 V)
Permitted ambient conditions
Ambient temperature During operation -20 °C to +70 °C
During storage -40 °C to +80 °C
During transportation
-40 °C to +80 °C
Relative humidity
During operation
≤ 95 % no condensation
Operating altitude During operation ≤ 2,000 m above sea level at max. 56 °C
ambient temperature
≤ 3,000 m above sea level at max. 50 °C
ambient temperature
