Siemens SCALANCE X-100 User Manual

Technical specifications
7.2 SCALANCE X106-1
SCALANCE X-100
Operating Instructions, 12/2016, A2B00060666-08
47
Technical specifications
Installation options
• Installation on a DIN rail
• Installation on an S7-300 standard rail
• Wall mounting
Switching properties
Aging time
30 seconds
Max. number of learnable MAC ad-
dresses
2048
Response to LLDP frames
Blocking
Response to spanning tree BPDU
frames
Forwarding
CoS acc. to IEEE 802.1Q
Yes
QoS priority queues
4
Note
The number of SCALANCE X Industrial Ethernet switches connected in a line influences the
frame delay time.
When a frame passes through devices of the SCALANCE X
-
100 product line, it is delayed by
the store and forward function of the switch
•
with a 64 byte frame length by approx. 10 microseconds (at 100 Mbps)
•
with a 1500 byte frame length by approx. 130 microseconds (at 100 Mbps)
This means that the more devices of the SCALANCE X
-100 product line, the frame passes
through, the longer the frame delay.
Note
Temperature code for c-UL-us for hazardous locations, FM and ATEX Zone 2
You will find the temperature code "T.." or the maximum ambient temperature "Ta: .." on the
type plate.
