7.4 SCALANCE X108PoE
SCALANCE X-100
Operating Instructions, 12/2016, A2B00060666-08
51
Technical specifications
Design, dimensions and weight
Immunity to interference
EN 61000-6-2
Emission
EN 61000-6-4
Degree of protection
IP 30
MTBF (EN/IEC 61709, 40 °C)
61.64 years
Housing material
Basic housing
Die cast aluminum, powder coated
Front cover Polyphenylene ether + polystyrene
(PPE+PS plastic)
Weight
550 g
Dimensions (W x H x D)
40 x 125 x 124 mm
Installation options
• Installation on a DIN rail
• Installation on an S7-300 standard rail
• Wall mounting
Switching properties
Aging time
30 seconds
Max. number of learnable MAC ad-
dresses
2048
Response to LLDP frames
Blocking
Response to spanning tree BPDU
frames
Forwarding
CoS acc. to IEEE 802.1Q
Yes
QoS priority queues
4
PoE properties
PoE standard 802.3af
Performance maximum 15.4 W
Note
As of an ambient temperature of 55 °
C, there must be a clearance of 40 mm to neighboring
devices on both sides.
Note
The number of SCALANCE X Industrial Ethernet switches connected in a line influences the
frame delay time.
When a frame passes through devices of the SCALANCE X
-100 produc
t line, it is delayed by
the store and forward function of the switch
•
with a 64 byte frame length by approx. 10 microseconds (at 100 Mbps)
•
with a 1500 byte frame length by approx. 130 microseconds (at 100 Mbps)
This means that the more devices of the SCALANCE X
-100 product line, the frame passes
through, the longer the frame delay.
