Technical specifications
7.5 SCALANCE X112-2
SCALANCE X-100
Operating Instructions, 12/2016, A2B00060666-08
53
Technical specifications
Attenuation ≤ 1 dB/km at 1300 nm
1200 MHz x km at 1300 nm
6 dB max. permitted FO cable attenuation with
3 dB link power margin
Electrical data
Power supply Voltage range 18 to 32 VDC Safe Extra Low Voltage
(SELV)
Rated voltage
24 VDC
Design
4-terminal plug-in block
Signaling contact
Current
max. 100 mA
Rated voltage
24 VDC
Design
2-pin plug-in terminal block
Current consumption
Typical
215 mA
Power loss at 24 VDC
Typical
5.16 W
Permitted ambient conditions
Ambient temperature
During operation
-10 °C to +70 ℃
During storage
-40 ℃ to +80 ℃
During transportation
-40 ℃ to +80 ℃
Relative humidity
During operation
≤ 95 % no condensation
Operating altitude During operation ≤ 2,000 m above sea level at max. 56 °C
ambient temperature
≤ 3,000 m above sea level at max. 50 °C
ambient temperature
Design, dimensions and weight
Immunity to interference
EN 61000-6-2
Emission
EN 61000-6-3
Degree of protection
IP 30
MTBF (EN/IEC 61709, 40 °C)
61.3 years
Housing material
Basic housing
Die cast aluminum, powder coated
Front cover Polyphenylene ether + polystyrene
(PPE+PS plastic)
Weight
1100 g
Dimensions (W x H x D)
120 x 125 x 124 mm
Installation options
• Installation on a DIN rail
• Installation on an S7-300 standard rail
• Wall mounting
Switching properties
Aging time
30 seconds
Max. number of learnable MAC ad-
dresses
2048
Response to LLDP frames
Blocking
Response to spanning tree BPDU
frames
Forwarding
