Logs
48
recorded. An example of data with both minimum and maximum
values is the voltage data.
To view the max/min voltage data, select
Volts
from the
Min/
Max Data Menu
. The following screen appears:
Then select
AB Line Volts
, for example, to see the minimum
and maximum values of the line-to-line (A-B) voltage:
The various data values for power included in the min/max logs
include instantaneous and demand values. From the
Min/Max
Data Menu
, select
Power
.
The following menu appears:
The maximum values for power are given for both forward and
reverse power:
To reset this log, select
Reset Min/Max Log
from the
Log
Menu
. Press the keypad arrow buttons until the Yes box is
checked. Press Escape , then press Enter to exit this
menu and reset the log.
