Testing
57
If you pressed the letter “A” to abort, you will be asked again:
Enter Test to perform
If you press ENTER, you will be prompted for the phase to
test: The TS-31 will display:
Enter phase to test.
7. Enter one of the following letters:
“A” - Phase A or left pole.
“B” - Phase B or center pole.
“C” - Phase C or right pole.
Press Enter again to start the test. Press any other key to
STOP the test.
Once a test has been started, the TS-31 will respond with:
Testing. Be careful at this time.
Any key press will abort the test
The test may take anywhere from a fraction of a second to
minutes to complete, depending on which procedure was
run. If the test passes, the display will show the following,
depending on whether the breaker tripped or not.
Passed Test xxx.xx seconds
Press ENTER to continue.
8. If the circuit breaker tripped during the test, RESET the cir-
cuit breaker before continuing.
The TS-31 will prompt for the next instructions. The display
will show:
Change: 1 - Test 2 - Catalog 3 - Settings
9. Enter one of the following numbers: “1” - Select a new test;
“2” - Enter a new catalog number; “3” - Enter new switch
settings.
If you enter “1” you will be sent to step 6. Choosing a “2”
will send the program back to step 3. Entering “3” sends
you back to step 5, which will be slightly different the sec-
ond time through.
On the second line after the prompt for the setting, a num-
ber or text in angle brackets will appear. This will indicate
the last setting you entered.
10. If you DON’T wish to change a setting, just press ENTER. If
you DO wish to change a setting, type in the new setting
and press ENTER.
11. In step 6, if you pressed “C” when asked
Enter test to perform; see instructions
you will first be prompted by,
Current Transformer Test
Press ENTER to continue or A to abort,
and then by the phase to test. One of the following mes-
sages will then appear depending on the test results:
CT Resistance Test. Phase X Passed
Press ENTER to exit test and continue
CT Resistance Test. Phase X Failed
Press ENTER to exit test and continue
CT Resistance Test. Phase X Open
Press ENTER to exit test and continue
CT Resistance Test. Phase X Short
Press ENTER to exit test and continue
The “Phase X Failed” message indicates that the CT resis-
tance is neither open nor shorted, but is not within design
tolerance.
13.3 Error Messages
There are additional ERROR messages which may appear on the
display during this operation which were not covered previously:
Test Not Running! Check test cable connection
Press ENTER to continue.
This message indicates that the test set has sensed that cur-
rent is not flowing properly in the breaker under test and that
there is either an open or short circuit between the TS-31 and
the breaker trip unit.
Function Not Available
Press ENTER to continue
You will get this error message if you enter a choice that is not
available, such as entering “G” in step 6 for ground fault test on
a catalog number that does not have the ground fault function.
Inconclusive Test, check settings
Press ENTER to continue or A to abort
This warning will appear if you attempt to run a short time test
with the instantaneous pickup set equal to or below the short
time pickup. It would also appear if you tried to run a long time
test with short time pickup set too low. This is only a warning;
the test can still be run. However, passing or failing the test
may not be conclusive.
Invalid Input
Press Enter to continue
