Parameter Settings
66
.
Long Time Protection
Settings
% I
n
50% 60% 65% 70% 75% 80% 85% 90% 95% 100%
I
n
= Rating Plug (A)
Pickup (A)
200 100 120 130 140 150 160 170 180 190 200
225 112 135 146 157 168 180 191 202 213 225
250 125 150 162 175 187 200 212 225 237 250
300 150 180 195 210 225 240 255 270 285 300
350 175 210 227 245 262 280 297 315 332 350
400 200 240 260 280 300 320 340 360 380 400
450 225 270 292 315 337 360 382 405 427 450
500 250 300 325 350 375 400 425 450 475 500
600 300 360 390 420 450 480 510 540 570 600
700 350 420 455 490 525 560 595 630 665 700
800 400 480 520 560 600 640 680 720 760 800
1000 500 600 650 700 750 800 850 900 950 1000
1200 600 720 780 840 900 960 1020 1080 1140 1200
1600 800 960 1040 1120 1200 1280 1360 1440 1520 1600
2000 1000 1200 1300 1400 1500 1600 1700 1800 1900 2000
2500 1250 1500 1625 1750 1875 2000 2125 2250 2375 2500
3000 1500 1800 1950 2100 2250 2400 2550 2700 2850 3000
3200 1600 1920 2080 2240 2400 2560 2720 2880 3040 3200
4000 2000 2400 2600 2800 3000 3200 3400 3600 3800 4000
5000 2500 3000 3250 3500 3750 4000 4250 4500 4750 5000
Long Time Protection
Delay Settings (at 6x)
Time (s)
2.5 4 5.5 8
10 14 17 21
25 30
