Siemens Sentron SB TP01 Series User Manual

Parameter Settings
73
Max Rating (A) Over kVA (kW)
400
20 40 60 80 100 125 150 175 200
225 250 275 300 325 350 375 400 425
800
40 80 120 160 200 250 300 350 400
450 500 550 600 650 700 750 800 850
1200
60 120 180 240 300 375 450 525 600
675 750 825 900 975 1050 1125 1200 1275
1600
80 160 240 320 400 500 600 700 800
900 1000 1100 1200 1300 1400 1500 1600 1700
2000
100 200 300 400 500 625 750 875 1000
1125 1250 1375 1500 1625 1750 1875 2000 2125
2500
125 250 375 500 625 800 950 1100 1250
1400 1550 1700 1875 2050 2200 2350 2500 2650
3200
160 320 480 640 800 1000 1200 1400 1600
1800 2000 2200 2400 2600 2800 3000 3200 3400
4000
200 400 600 800 1000 1250 1500 1750 2000
2250 2500 2750 3000 3250 3500 3750 4000 4250
5000
250 500 750 1000 1250 1550 1875 2200 2500
2800 3125 3450 3750 4050 4375 4700 5000 5300
Max Rating (A) Over kVAR (kW)
400
20 40 60 80 100 125 150 175 200
225 250 275 300 325 350 375 400 425
800
40 80 120 160 200 250 300 350 400
450 500 550 600 650 700 750 800 850
1200
60 120 180 240 300 375 450 525 600
675 750 825 900 975 1050 1125 1200 1275
1600
80 160 240 320 400 500 600 700 800
900 1000 1100 1200 1300 1400 1500 1600 1700
2000
100 200 300 400 500 625 750 875 1000
1125 1250 1375 1500 1625 1750 1875 2000 2125
2500
125 250 375 500 625 800 950 1100 1250
1400 1550 1700 1875 2050 2200 2350 2500 2650
3200
160 320 480 640 800 1000 1200 1400 1600
1800 2000 2200 2400 2600 2800 3000 3200 3400
4000
200 400 600 800 1000 1250 1500 1750 2000
2250 2500 2750 3000 3250 3500 3750 4000 4250
5000
250 500 750 1000 1250 1550 1875 2200 2500
2800 3125 3450 3750 4050 4375 4700 5000 5300
