Page #37 background image
Parameter
5.3 Configuration control (option handling)
Interface module IM 155-5 MF HF (6ES7155-5MU00-0CN0)
36 Equipment Manual, 11/2023, A5E53268530-AA
Rules: Arrangement of the modules
The following table shows the slot number assignment:
Table 5- 2 Assignment of slot numbers
Slot
Modules
Note
0
Power supply module (optional)
Before the interface module
1 Interface module Interface module (slot 1) is not an ele-
ment of the configuration control, but
rather controls this
2 - 31 I/O modules /
max. 2 power supply modules, depending
on the configuration variant
After the interface module
Control data record
A control data record 196 is defined for the configuration control that receives a slot
assignment.
Table 5- 3 Control data record
Byte
Element
Code
Explanation
0
Block length
4 + number of slots
Header
1
Block ID
196
2
Version
3
3
Version
0
4 Assignment of config-
ured slot 0
Real slot 0 Control element
Describes in each
element which real
slot in the device is
assigned to the con-
figured slot.
5 Assignment of config-
ured slot 2
Real slot 2
:
:
:
4 + (max. slot - 1)
Assignment of config-
ured maximum slot
Real maximum slot
Control element
Each element must include the following information about the slot:
Assignment of configured slot real slot
Table 5- 4 Code of control element
Byte
Bit
Meaning
Assignment of configured slot
(e.g. in byte 5)
0 to 7
01111111: Module not available
00000000 up to maximum slot: Real slot
