Interrupts and diagnostic, error, and system alarms
6.3 Alarms
Interface module IM 155-5 MF HF (6ES7155-5MU00-0CN0)
54 Equipment Manual, 11/2023, A5E53268530-AA
6.3.3 Channel diagnostics
Function
Channel diagnostics provides information about channel faults in modules.
Channel faults are mapped as channel diagnostics in IO diagnostic data records.
The "RDREC" instruction is used to read the data record.
Structure of the diagnostic data records
• The IM 155-5 MF HF interface module maps channel faults by means of extended channel
diagnostics.
The data records supported by the ET 200MP are based on the standard PROFINET IO -
Application Layer Service Definition V2.3.
You can purchase the standards from the PROFIBUS User Organization on the Internet
(http://www.profibus.com).
Codes of the extended channel diagnostics
With the IM 155-5 MF HF interface module, the following extended channel diagnostics are
reported by the interface module in slot 1:
Table 6- 4 Manufacturer-specific diagnostics in the USI
ChannelError-
Type
ExtendedChan-
nel
Associated value
(AddValue)
Diagnostics
Communication with slot <No.> has failed
Permitted number of I/O modules exceeded
Interface module in incorrect slot
Permitted number of power supply modules exceeded
No U connector detected on an IM port
More than one bus master module (IM/CPU) detected
Power budget error (overload has been detected in at least one
power segment)
0x0610 0x06B2 0 Error IM power supply: Power supply not active or power supply
Diagnostics with incorrectly plugged BusAdapter
