Siemens simatic ET 200MP - Errors;Accuracies; Operational Error Limit in Overall Temperature Range

Parameter
5.3 Configuration control (option handling)
Interface module IM 155-5 MF HF (6ES7155-5MU00-0CN0)
40 Equipment Manual, 11/2023, A5E53268530-AA
Error messages
The following error messages are returned if an error occurs during reading of the feedback
data record:
Table 5- 7 Error messages
Error code
Meaning
80B1H
Invalid length
80B5H
Configuration control not configured
80B8
H
Parameter error
5.3.3 Configure configuration control without empty slots
Operating principle
The modules actually not required do not exist. The configuration is pushed together to the
left in the direction of IM 155-5 MF HF.
Figure 5-1 Configure configuration control without empty slots
