Siemens simatic ET 200MP Equipment Manual

Parameter
5.3 Configuration control (option handling)
Interface module IM 155-5 MF HF (6ES7155-5MU00-0CN0)
Equipment Manual, 11/2023, A5E53268530-AA
41
Data record of the example
The following table shows the structure of the control data record for the above example.
Table 5- 8 Data record for example "Configure configuration control without empty slots"
Byte
Element
Code
Explanation
0
Block length
18
Header
1
Block ID
196
2
Version
3
3
Version
0
4
Slot 0
00000000B
The configured slot 0 is the real slot 0.
5
Slot 2
00000010B
The configured slot 2 is the real slot 2.
6
Slot 3
00000011B
The configured slot 3 is the real slot 3.
7
Slot 4
00000100B
The configured slot 4 is the real slot 4.
8
Slot 5
00000101B
The configured slot 5 is the real slot 5.
9
Slot 6
01111111B
The configured slot 6 does not exist.
10
Slot 7
01111111B
The configured slot 7 does not exist.
11
Slot 8
00000110
B
The configured slot 8 is the real slot 6.
12
Slot 9
00000111B
The configured slot 9 is the real slot 7.
13
Slot 10
01111111B
The configured slot 10 does not exist.
14
Slot 11
01111111
B
The configured slot 11 does not exist.
15
Slot 12
00001000B
The configured slot 12 is the real slot 8.
16
Slot 13
00001001B
The configured slot 13 is the real slot 9.
17
Slot 14
00001010B
The configured slot 14 is the real slot 10.
