5.3 Configuration control (option handling)
Interface module IM 155-5 MF HF (6ES7155-5MU00-0CN0)
Equipment Manual, 11/2023, A5E53268530-AA
39
5.3.2 Feedback data record
Feedback data record
The feedback data record provides information on the accuracy of the module assignment
and gives you the chance to detect assignment errors in the control data record. The
feedback data record is mapped by a separate data record 197.
The feedback data record exists only when configuration control is configured and always
refers to the maximum quantity framework without interface module, i.e., 31 slots.
The following applies here:
• The power supply (PS) module is inserted in "Slot 0" before the interface module
• Starting from "Slot 2", a maximum of 30 modules follow after the interface module.
Partial reading of the feedback data record is possible.
Table 5- 6 Feedback data record
Byte
Element
Code
Meaning
0
Block length
66
Header
1
Block ID
197
2
Version
2
3
0
4
Slot 0 status
0/1
Bit 0 = 1:
• Configured module is inserted
• Slot is marked as not available in the control
data record
Bit 0 = 0:
• Module pulled
• Wrong module inserted*
Bits 1 to 15: Reserved
5
Reserved
0
6
Slot 2 status
0/1
7
Reserved
0
:
:
:
64
Slot n status
Maximum slot
65 Reserved 0
* Not possible if the slot is marked as not available.
Note
The data in the feedback data record are always mapped for all modules. In a Shared Device
configuration it is therefore irrelevant which controller the respective modules are assigned
to.
As long as no control data record was sent, a one
-to-one module assignment is assumed for
the compilation of data record 197 (preset configuration → actual configuration).
