6.3 Alarms
6.3.1 Diagnostic alarms
Actions after a diagnostic alarm
There can be more than one diagnostic alarm at the same time. Each diagnostic alarm
initiates the following actions:
• The ERROR LED of the interface module flashes.
• Diagnostics are reported as diagnostic interrupts to the CPU of the IO controller and can be
read via data records.
• Incoming diagnostic alarms are saved to the diagnostic buffer of the IO controller.
• (S7-300/400) The diagnostic interrupt OB is called. If the diagnostic interrupt OB (OB82) is
not available, the IO controller goes into STOP mode.
You can find additional information in the STEP 7 online help.
Reading out the diagnostics
Table 6- 2 Reading out the diagnostics with STEP 7
Automation system
Application See...
Diagnostics as plain text in STEP 7
using online view and diagnostic
Online help of STEP 7 and
• As of STEP 7 V12 PROFINET with STEP 7
V12 function manual
(http://support.automation.siemens.co
m/WW/view/en/49948856)
• As of STEP 7 V5.5 PROFINET System
Description
(http://support.automation.siemens.co
m/WW/view/en/19292127) manual.
Read data records from the IO
Receive interrupts from the IO
device
Additional information on the data records for PROFINET IO
You can find the structure of the diagnostic data records and programming examples in the
programming manual From PROFIBUS DP to PROFINET IO
(http://support.automation.siemens.com/WW/view/en/19289930) and in the application
example on the Internet (http://support.automation.siemens.com/WW/view/en/24000238).
