Siemens simatic ET 200MP Equipment Manual

Parameter
5.3 Configuration control (option handling)
Interface module IM 155-5 MF HF (6ES7155-5MU00-0CN0)
Equipment Manual, 11/2023, A5E53268530-AA
43
Data record of the example
The following table shows the structure of the control data record for the above example.
Table 5- 9 Data record for example "Extending the configuration"
Byte
Element
Code
Explanation
0
Block length
17
Header
1
Block ID
196
2
Version
3
3
Version
0
4
Slot 0
00000000B
The configured slot 0 is the real slot 0.
5
Slot 2
00000010B
The configured slot 2 is the real slot 2.
6
Slot 3
00000011B
The configured slot 3 is the real slot 3.
7
Slot 4
00000100B
The configured slot 4 is the real slot 4.
8
Slot 5
00000101B
The configured slot 5 is the real slot 5.
9
Slot 6
00001011B
The configured slot 6 is the real slot 11.
10
Slot 7
00001100B
The configured slot 7 is the real slot 12.
11
Slot 8
00001101
B
The configured slot 8 is the real slot 13.
12
Slot 9
00001001B
The configured slot 9 is the real slot 9.
13
Slot 10
00001010B
The configured slot 10 is the real slot 10.
14
Slot 11
00000110
B
The configured slot 11 is the real slot 6.
15
Slot 12
00000111B
The configured slot 12 is the real slot 7.
16
Slot 13
00001000B
The configured slot 13 is the real slot 8.
