Connecting
3.1 Wiring and block diagram
Analog input module F-AI 4xI 0(4)..20mA 2-/4-wire HF (6ES7136-6AA00-0CA1)
18 Manual, 08/2018, A5E41448857-AB
Recommendation: Internal sensor supply
You are strongly advised to use the short circuit-proof internal sensor supply of the F-
module. This internal sensor supply is monitored and its status is indicated by the Fn LED.
The input is also protected in the event of short-circuits in the wiring or at the sensor.
Note
The internal sensor supply is switched off in case of a short circuit to ground or during
power
-up in the event of short circuit to L+.
The sensor supply is also switched off at input currents > 35 mA.
A check is made approximately 1 minute later to determ
ine if the error has gone.
Note
Behavior of process values and diagnostics evaluation
Sensor startup during module startup:
After the internal sensor supply is activated, the evaluation of wire break and underflow
diagnostics is suppressed for 3
seconds. During this time, the module makes the secure
process data 0 available at all channels. This suppresses a possible wire break or underflow
diagnostics caused by the sensor startup. If the sensor startup is not yet complete after the 3
seconds have elap
sed, it is possible that the module might detect wire break or underflow
and passivate the affected channel. In this case, the channel fault must be acknowledged
during startup.
Sensor startup during operation:
If a sensor startup takes place during operat
ion, e.g. the sensor supply is reactivated after a
short
-circuit, all analog values are invalid and wire break or underflow diagnostics can occur
on the sensors connected to the internal sensor supply.

Siemens SIMATIC ET 200SP F-AI 4xI 0(4) 20mA 2-/4-wire HF Series Specifications

General

Input channels	4
Wiring type	2-/4-wire
Series	SIMATIC ET 200SP
Supply voltage	24 V DC
Rated value (DC)	24 V
Power loss, typ.	1.5 W
Interference voltage suppression for interference frequency f1 in Hz	50/60 Hz
Diagnostics function	Yes
Galvanic isolation	Yes
Potential separation channels	Yes
Potential separation between the channels and backplane bus	Yes
Module type	AI
Safety integrity level	SIL 3
Connection method	Push-in terminals
Operating voltage	24 V DC
Weight	200 g
Input current range	0(4)..20 mA
Product type designation	F-AI 4xI 0(4)..20mA 2-/4-wire HF
Analog value generation for the inputs	16 bits
Resolution	16 bit
Integration time/resolution per channel	Configurable
