Siemens SIMATIC ET 200SP F-AI 4xI 0(4) 20mA 2-/4-wire HF Series User Manual

Analog input module F-AI 4xI 0(4)..20mA 2-/4-wire HF (6ES7136-6AA00-0CA1)
Manual, 08/2018, A5E41448857-AB
71
Representation of analog values
B
In this section we are presenting the analog values for all measuring ranges that you can use
with the F-AI 4xI 0(4)..20mA 2-/4-wire HF analog input module.
Measured value resolution
The analog values are shown as fixed-point number in two's complement.
The resolutions shown here are 16 bits including sign.
Table B- 1 Resolution of the analog values
Resolution in bits
Values
Analog value
Decimal
Hexadecimal
High byte
Low byte
16
1
1
H
Sign 0 0 0 0 0 0 0
0 0 0 0 0 0 0 1

Siemens SIMATIC ET 200SP F-AI 4xI 0(4) 20mA 2-/4-wire HF Series Specifications

General

Input channels	4
Wiring type	2-/4-wire
Series	SIMATIC ET 200SP
Supply voltage	24 V DC
Rated value (DC)	24 V
Power loss, typ.	1.5 W
Interference voltage suppression for interference frequency f1 in Hz	50/60 Hz
Diagnostics function	Yes
Galvanic isolation	Yes
Potential separation channels	Yes
Potential separation between the channels and backplane bus	Yes
Module type	AI
Safety integrity level	SIL 3
Connection method	Push-in terminals
Operating voltage	24 V DC
Weight	200 g
Input current range	0(4)..20 mA
Product type designation	F-AI 4xI 0(4)..20mA 2-/4-wire HF
Analog value generation for the inputs	16 bits
Resolution	16 bit
Integration time/resolution per channel	Configurable
