Siemens SIMATIC ET 200SP F-AI 4xI 0(4) 20mA 2-/4-wire HF Series User Manual

Analog input module F-AI 4xI 0(4)..20mA 2-/4-wire HF (6ES7136-6AA00-0CA1)
64 Manual, 08/2018, A5E41448857-AB
Technical specifications
7
7.1
Technical specifications
Technical specifications of the F-AI 4xI 0(4)..20mA 2-/4-wire HF
Article number
6ES7136-6AA00-0CA1
General information
Product type designation F-AI 4xI 0(4) ... 20 mA 2/4-wire HF
Firmware version
• FW update possible
Yes
usable BaseUnits BU type A0, A1
Color code for module-specific color identification
plate
CC00
Product function
• I&M data
Yes; I&M0 to I&M3
Engineering with
• STEP 7 TIA Portal configurable/integrated as of
version
V15 with HSP 203
CiR – Configuration in RUN
Reparameterization possible in RUN
No
Calibration possible in RUN
No
Supply voltage
Rated value (DC)
24 V
permissible range, lower limit (DC)
19.2 V
permissible range, upper limit (DC)
28.8 V
Reverse polarity protection
Yes
Input current
Current consumption (rated value)
0.38 A
Current consumption, max.
0.4 A
24 V encoder supply
• 24 V
Yes; min. L+ (-1.5 V)
• Short-circuit protection
Yes
• Output current, max.
300 mA; total current of all encoders/
channels
Power
Power available from the backplane bus 70 mW
Power loss
Power loss, typ.
2 W

Siemens SIMATIC ET 200SP F-AI 4xI 0(4) 20mA 2-/4-wire HF Series Specifications

General

Input channels	4
Wiring type	2-/4-wire
Series	SIMATIC ET 200SP
Supply voltage	24 V DC
Rated value (DC)	24 V
Power loss, typ.	1.5 W
Interference voltage suppression for interference frequency f1 in Hz	50/60 Hz
Diagnostics function	Yes
Galvanic isolation	Yes
Potential separation channels	Yes
Potential separation between the channels and backplane bus	Yes
Module type	AI
Safety integrity level	SIL 3
Connection method	Push-in terminals
Operating voltage	24 V DC
Weight	200 g
Input current range	0(4)..20 mA
Product type designation	F-AI 4xI 0(4)..20mA 2-/4-wire HF
Analog value generation for the inputs	16 bits
Resolution	16 bit
Integration time/resolution per channel	Configurable
