Siemens SIMATIC ET 200SP F-AI 4xI 0(4) 20mA 2-/4-wire HF Series User Manual

Analog input module F-AI 4xI 0(4)..20mA 2-/4-wire HF (6ES7136-6AA00-0CA1)
Manual, 08/2018, A5E41448857-AB
3
Preface
Purpose of the documentation
This manual supplements the system manual Distributed I/O System ET 200SP
(http://support.automation.siemens.com/WW/view/en/58649293).
Functions that affect the system in general are described in the system manual.
The information in this manual and the system/function manuals provide support when you
commission the system.
A description of the F-system SIMATIC Safety can be found in the programming and
operating manual SIMATIC Safety – Configuring and Programming
(http://support.automation.siemens.com/WW/view/en/54110126).
Conventions
CPU: When the term "CPU" is used hereafter, it refers to both the CPUs of the S7-
1200/1500 automation system and CPUs of the ET 200SP distributed I/O system.
STEP 7: In this documentation, "STEP 7" is used as a synonym for all versions of the
configuration and programming software " (STEP 7 TIA Portal)".
Note the following identified notes:
Note
A note includes important info
rmation on the product described in the documentation, on
handling the product or on the part of the documentation to which you ought to pay special
attention.
Standards
You can find a dated reference to the respective standards in the certificate
(https://support.industry.siemens.com/cs/ww/en/view/57141281) or in the EC Declaration of
Conformity (https://support.industry.siemens.com/cs/ww/en/view/71764057) for the F-
module.
Certified versions
You can find the certified product and firmware versions in annex 1 of the report on the TÜV
certificate (https://support.industry.siemens.com/cs/ww/en/view/57141289).

Siemens SIMATIC ET 200SP F-AI 4xI 0(4) 20mA 2-/4-wire HF Series Specifications

General

Input channels	4
Wiring type	2-/4-wire
Series	SIMATIC ET 200SP
Supply voltage	24 V DC
Rated value (DC)	24 V
Power loss, typ.	1.5 W
Interference voltage suppression for interference frequency f1 in Hz	50/60 Hz
Diagnostics function	Yes
Galvanic isolation	Yes
Potential separation channels	Yes
Potential separation between the channels and backplane bus	Yes
Module type	AI
Safety integrity level	SIL 3
Connection method	Push-in terminals
Operating voltage	24 V DC
Weight	200 g
Input current range	0(4)..20 mA
Product type designation	F-AI 4xI 0(4)..20mA 2-/4-wire HF
Analog value generation for the inputs	16 bits
Resolution	16 bit
Integration time/resolution per channel	Configurable
