Parameters/address space
4.3 Explanation of parameters
Analog input module F-AI 4xI 0(4)..20mA 2-/4-wire HF (6ES7136-6AA00-0CA1)
34 Manual, 08/2018, A5E41448857-AB
4.3.2.8
Activated
If you select this check box, the corresponding channel is enabled for signal processing.
You can deactivate an unused channel with this parameter.
If you deactivate unused channels, the response time of the F-module is reduced.
4.3.2.9
Channel failure acknowledge
Use on S7-1200/1500 F-CPUs
The parameter is only relevant if the F-module can be operated on an S7-1200/1500 F-CPU.
The parameter can only be set if the F-parameter "Behavior after channel fault" is set to
"Passivate channel" and the F-parameter "Reintegration after channel fault" is set to
"Adjustable".
The value of this parameter specifies how the channel reacts after a channel fault:
● Manual: A channel failure is reintegrated after manual acknowledgment.
● Automatically: The channel is reintegrated automatically after a channel fault. Manual
acknowledgment is not necessary.
Use in S7-300/400 F-CPUs
The value of this parameter is not relevant in the case of operation on S7-300/400 F-CPUs.
For S7-300/400 F-CPUs you set the corresponding property at the F-I/O DB by means of the
ACK_NEC tag.
For detailed information about the F-I/O DB, refer to the SIMATIC Safety – Configuring and
Programming (http://support.automation.siemens.com/WW/view/en/54110126) manual.
4.3.2.10
Measuring range
You select the measuring range for the channel with this parameter:
● 0 to 20 mA
● 4 to 20 mA

Siemens SIMATIC ET 200SP F-AI 4xI 0(4) 20mA 2-/4-wire HF Series Specifications

General

Input channels	4
Wiring type	2-/4-wire
Series	SIMATIC ET 200SP
Supply voltage	24 V DC
Rated value (DC)	24 V
Power loss, typ.	1.5 W
Interference voltage suppression for interference frequency f1 in Hz	50/60 Hz
Diagnostics function	Yes
Galvanic isolation	Yes
Potential separation channels	Yes
Potential separation between the channels and backplane bus	Yes
Module type	AI
Safety integrity level	SIL 3
Connection method	Push-in terminals
Operating voltage	24 V DC
Weight	200 g
Input current range	0(4)..20 mA
Product type designation	F-AI 4xI 0(4)..20mA 2-/4-wire HF
Analog value generation for the inputs	16 bits
Resolution	16 bit
Integration time/resolution per channel	Configurable
