Interrupts/diagnostic messages
6.3 Diagnostic messages
Analog input module F-AI 4xI 0(4)..20mA 2-/4-wire HF (6ES7136-6AA00-0CA1)
58 Manual, 08/2018, A5E41448857-AB
6.3
Diagnostic messages
Diagnostic messages
Module faults are indicated as diagnostics (module status).
Once the fault is eliminated, the F-module must be reintegrated in the safety program. For
additional information on passivation and reintegration of F-I/O, refer to the SIMATIC Safety
– Configuring and Programming
(http://support.automation.siemens.com/WW/view/en/54110126) manual.
Table 6- 5 Diagnostic messages of the F-AI 4xI 0(4)..20mA 2-/4-wire HF
Diagnostic message
Fault
code
Meaning
Remedy
Overtemperature 5
H
The F-module measured an excessively
high temperature.
Operate the F-module within the speci-
fied temperature range (see Technical
specifications (Page 64))
Once the temperature has been re-
duced and returns to the specified
range, the F-module must be removed
and inserted or the power switched
OFF and ON.
Wire break 6
H
Possible causes:
• A cable to the sensor is broken.
• Fault at the external circuit
• Defective sensor
• Wrong sensor type set in the parame-
ters
• Input channel not used
• Measurement resistance too high
Check the possible causes and elimi-
nate the fault.
High limit exceeded 7
H
The measured value exceeds the meas-
uring range.
Check the interaction between the
module and the sensor.
Low limit violated 8
H
The measured input value is below a
measuring range.
Check the interaction between the
module and the sensor.
Parameter error 10
H
Parameter assignment errors include:
• The F-module cannot use the param-
eters (unknown, invalid combination,
etc.).
• The F-module parameters have not
been configured.
Correct the parameter assignment.
Supply voltage missing 11
H
Missing or insufficient supply voltage L+
• Check the supply voltage L+ on the
BaseUnit.
• Check the BaseUnit.

Siemens SIMATIC ET 200SP F-AI 4xI 0(4) 20mA 2-/4-wire HF Series Specifications

General

Input channels	4
Wiring type	2-/4-wire
Series	SIMATIC ET 200SP
Supply voltage	24 V DC
Rated value (DC)	24 V
Power loss, typ.	1.5 W
Interference voltage suppression for interference frequency f1 in Hz	50/60 Hz
Diagnostics function	Yes
Galvanic isolation	Yes
Potential separation channels	Yes
Potential separation between the channels and backplane bus	Yes
Module type	AI
Safety integrity level	SIL 3
Connection method	Push-in terminals
Operating voltage	24 V DC
Weight	200 g
Input current range	0(4)..20 mA
Product type designation	F-AI 4xI 0(4)..20mA 2-/4-wire HF
Analog value generation for the inputs	16 bits
Resolution	16 bit
Integration time/resolution per channel	Configurable
