Analog input module F-AI 4xI 0(4)..20mA 2-/4-wire HF (6ES7136-6AA00-0CA1)
40 Manual, 08/2018, A5E41448857-AB
Applications of the F-I/O module
5
You achieve SIL3/Cat.4/PLe with the following applications.
The wiring is performed on the suitable BaseUnit. Additional information is available in the
Connecting section in the Distributed I/O System ET 200SP
(http://support.automation.siemens.com/WW/view/en/58649293) System Manual.
5.1
Application 1: Safety mode SIL3/Cat.3/PLd with 2-wire transducer
Introduction
Below you will find the wiring scheme and the parameter assignment of the F-AI 4xI
0(4)..20mA 2-/4-wire HF for
● Application 1: Safety mode SIL3/Cat.3/PLd, 1oo1 (1v1) evaluation.
Possible diagnostic messages, the error causes and possible corrective measures are given
in section "Diagnostic messages (Page 58)".
