Siemens SIMATIC ET 200SP F-AI 4xI 0(4) 20mA 2-/4-wire HF Series User Manual

Analog input module F-AI 4xI 0(4)..20mA 2-/4-wire HF (6ES7136-6AA00-0CA1)
20 Manual, 08/2018, A5E41448857-AB
Parameters/address space
4
4.1
Measurement types and measuring ranges
The following table shows the measurement types and the respective measuring range.
Table 4- 1 Measurement types and measuring ranges
Measurement
type
Measuring range
Resolution
Current 0 to 20 mA (2-wire and 4-wire transducer)
4 to 20 mA (2-wire and 4-wire transducer)
16 bits including sign
16 bits including sign
You can find the tables of the measuring ranges as well as overflow, overrange, etc. in the
Appendix Representation of analog values (Page 71).
4.2
Parameters
Parameters for F-AI 4xI 0(4)..20mA 2-/4-wire HF
WARNING
Diagnostics functions should be activated or deactivated in accordance with the application,
see section Applications of the F-I/O module (Page 40).
The following parameters are possible:
Table 4- 2 Configurable parameters
Parameters
Value range
Default
Parameter reas-
signment in RUN
Scope
F-parameters:
Manual assignment of the F-
monitoring time
• Disable
• Enable
Disable No Module
F-monitoring time
1 to 65535 ms
150 ms
No
Module
F-source address 1 to 65534 depends on parame-
ter assignment of F-
CPU
No Module
F-destination address 1 to 65534 suggested by F-
system
No Module
F-parameter signature (with-
out address)
0 to 65535 calculated by F-
system
No Module

Siemens SIMATIC ET 200SP F-AI 4xI 0(4) 20mA 2-/4-wire HF Series Specifications

General

Input channels	4
Wiring type	2-/4-wire
Series	SIMATIC ET 200SP
Supply voltage	24 V DC
Rated value (DC)	24 V
Power loss, typ.	1.5 W
Interference voltage suppression for interference frequency f1 in Hz	50/60 Hz
Diagnostics function	Yes
Galvanic isolation	Yes
Potential separation channels	Yes
Potential separation between the channels and backplane bus	Yes
Module type	AI
Safety integrity level	SIL 3
Connection method	Push-in terminals
Operating voltage	24 V DC
Weight	200 g
Input current range	0(4)..20 mA
Product type designation	F-AI 4xI 0(4)..20mA 2-/4-wire HF
Analog value generation for the inputs	16 bits
Resolution	16 bit
Integration time/resolution per channel	Configurable
