Applications of the F-I/O module
5.1 Application 1: Safety mode SIL3/Cat.3/PLd with 2-wire transducer
Analog input module F-AI 4xI 0(4)..20mA 2-/4-wire HF (6ES7136-6AA00-0CA1)
Manual, 08/2018, A5E41448857-AB
43
Assignable parameters for application 1
Table 5- 1 Parameters for application 1 of F-AI 4xI 0(4)..20mA 2-/4-wire HF
Parameters
Range of values in safety mode
Behavior after channel faults
• Passivate the entire F-module
• Passivate channel
Interference frequency suppression
• 50 Hz
• 60 Hz
Sensor evaluation
1oo1 evaluation (max. SIL3/Cat.3/PLd)
Measuring range
• 0 ... 20 mA
• 4 ... 20 mA
Diagnostics: Wire break (in the measuring range 4 to 20 mA)
• Disable
• Enable
Smoothing
1 / 2 / 4 / 8 / 16 / 32 / 64 conversion cycles

Siemens SIMATIC ET 200SP F-AI 4xI 0(4) 20mA 2-/4-wire HF Series Specifications

General

Input channels	4
Wiring type	2-/4-wire
Series	SIMATIC ET 200SP
Supply voltage	24 V DC
Rated value (DC)	24 V
Power loss, typ.	1.5 W
Interference voltage suppression for interference frequency f1 in Hz	50/60 Hz
Diagnostics function	Yes
Galvanic isolation	Yes
Potential separation channels	Yes
Potential separation between the channels and backplane bus	Yes
Module type	AI
Safety integrity level	SIL 3
Connection method	Push-in terminals
Operating voltage	24 V DC
Weight	200 g
Input current range	0(4)..20 mA
Product type designation	F-AI 4xI 0(4)..20mA 2-/4-wire HF
Analog value generation for the inputs	16 bits
Resolution	16 bit
Integration time/resolution per channel	Configurable
