Siemens SIMATIC ET 200SP F-AI 4xI 0(4) 20mA 2-/4-wire HF Series User Manual

Interrupts/diagnostic messages
6.1 Status and error display
Analog input module F-AI 4xI 0(4)..20mA 2-/4-wire HF (6ES7136-6AA00-0CA1)
Manual, 08/2018, A5E41448857-AB
55
Channel status/DIAG/channel fault LED
Table 6- 3 Status display of the LEDs channel status / DIAG / channel error
Channel
status
DIAG
Channel
fault
Meaning
Off
Flash-
ing
All On
The PROFIsafe address does not match the configured PROFIs-
afe address.
Flashing Flash-
ing
Off
Identification of the F-module when assigning the PROFIsafe ad-
dress.
PWR LED
Table 6- 4 Status display of LED PWR
PWR
Meaning
Off
Supply voltage L+ missing
On
Supply voltage L+ available

Siemens SIMATIC ET 200SP F-AI 4xI 0(4) 20mA 2-/4-wire HF Series Specifications

General

Input channels	4
Wiring type	2-/4-wire
Series	SIMATIC ET 200SP
Supply voltage	24 V DC
Rated value (DC)	24 V
Power loss, typ.	1.5 W
Interference voltage suppression for interference frequency f1 in Hz	50/60 Hz
Diagnostics function	Yes
Galvanic isolation	Yes
Potential separation channels	Yes
Potential separation between the channels and backplane bus	Yes
Module type	AI
Safety integrity level	SIL 3
Connection method	Push-in terminals
Operating voltage	24 V DC
Weight	200 g
Input current range	0(4)..20 mA
Product type designation	F-AI 4xI 0(4)..20mA 2-/4-wire HF
Analog value generation for the inputs	16 bits
Resolution	16 bit
Integration time/resolution per channel	Configurable
