Compatibility
6.1 Compatibility of modules
Interface module IM 155-6 DP HF (6ES7155-6BA01-0CN0)
50 Manual, 10/2018, A5E03916550-AD
Plugging and pulling (hot-swapping) of ET 200SP I/O modules
NOTICE
Pulling and plugging (hot swapping) of ET 200SP I/O modules during operation on S7-300
via PROFIBUS
DP
ET 200SP I/O modules can be pulled and plugged:
• As of STEP7 V5.5 SP3 HSP 242 and
• If "Operation if preset configuration <> actual configuration" parameter is enabled.
Note the following when operating the ET 200SP with S7-300 via PROFIBUS DP: Plugging
of ET 200SP I/O modules results in a brief station failure of the ET 200SP.
Note
ET 200SP I/O modules can be pulled and plugged without restrictions for all other DP master
systems if you enable the "Pull/plug module (OB83)" parameter.
Communication module IO-Link Master CM 4xIO-Link
Note
Communication module IO-Link Master CM 4xIO-Link
Operation of the CM
4xIO-Link IO-Link Master communication module with the IM 155-
6
DP HF interface module is supported as of S7-PCT V3.1 and an updated module firmware
version/GSD file.
Reaction times for fail-safe modules
The following maximum reaction time of the interface module must be taken into account
when calculating the reaction times of fail-safe modules:
Maximum reaction time = 2.3 ms

Siemens SIMATIC ET 200SP IM 155-6 DP HF Specifications

General

Product type designation	IM 155-6 DP HF
Manufacturer	Siemens
Series	SIMATIC ET 200SP
Interface	PROFIBUS DP
Protocol	PROFIBUS DP
Power Supply	24 V DC
Number of DP masters	1
DP master	Yes
Isochronous mode	Yes
Integrated web server	Yes
PROFINET IO Device	No
Number of IO controllers	0
IRT	No
MRP	No
MRPD	No
Shared device	No
Rated value (DC)	24 V
Permissible range, upper limit (DC)	28.8 V
Reverse polarity protection	Yes
Protection class	IP20
Mounting	DIN rail
Transmission rate	12 Mbps
Address area	244 bytes
I&M data	Yes
Number of S7 program blocks	0
Number of clock memories	0
Number of counters	0
Number of data blocks	0
Number of timers	0
Operating temperature	60 °C
Storage temperature	-40 °C to +70 °C
Relative humidity	95%
