Compatibility
6.1 Compatibility of modules
Interface module IM 155-6 DP HF (6ES7155-6BA01-0CN0)
Manual, 10/2018, A5E03916550-AD
51
First BaseUnit of an ET 200SP in the configuration
The interface modules support plugging a dark-colored BaseUnit in slot 1. This means that
modules without a connection to the integrated voltage buses P1 and P2 can now also be
configured starting with slot 1. Currently, this applies to the following modules:
● AI EnergyMeter ST (6ES7134-6PA00-0BD0)
● DI 4x120 … 230VAC ST (6ES7131-6FD00-0BB1)
● DQ 4x24 … 230VAC/2A ST (6ES7132-6FD00-0BB1)
Note
First BaseUnit of an ET 200SP in the configuration
Please note the i
nformation on limiting the overvoltage and power rating in the AC I/O
module manuals.
The 24 V
DC supply voltage is fed in via an external fuse.
The 24
V DC supply voltage is provided by a light-colored BaseUnit.
Requirement for configuration of these modules in slot 1:
● Configuration via GSD or GSDML
● Configuration as of STEP7 V5.5 SP4 as of
– HSP0242 V2.0 for IM155-6 DP HF
● Configuration as of STEP7 V13 SP1
See also: Functions (Page 14)

Siemens SIMATIC ET 200SP IM 155-6 DP HF Specifications

General

Product type designation	IM 155-6 DP HF
Manufacturer	Siemens
Series	SIMATIC ET 200SP
Interface	PROFIBUS DP
Protocol	PROFIBUS DP
Power Supply	24 V DC
Number of DP masters	1
DP master	Yes
Isochronous mode	Yes
Integrated web server	Yes
PROFINET IO Device	No
Number of IO controllers	0
IRT	No
MRP	No
MRPD	No
Shared device	No
Rated value (DC)	24 V
Permissible range, upper limit (DC)	28.8 V
Reverse polarity protection	Yes
Protection class	IP20
Mounting	DIN rail
Transmission rate	12 Mbps
Address area	244 bytes
I&M data	Yes
Number of S7 program blocks	0
Number of clock memories	0
Number of counters	0
Number of data blocks	0
Number of timers	0
Operating temperature	60 °C
Storage temperature	-40 °C to +70 °C
Relative humidity	95%
