Siemens SIMATIC ET 200SP IM 155-6 DP HF User Manual

Technical specifications
7.1 Technical specifications
Interface module IM 155-6 DP HF (6ES7155-6BA01-0CN0)
Manual, 10/2018, A5E03916550-AD
53
Article number
6ES7155-6BA01-0CN0
Address area
Address space per module
• Address space per module, max.
32 byte; per input / output
Address space per station
• Address space per station, max.
244 byte; per input / output
Hardware configuration
Rack
• Modules per rack, max.
32; + 16 ET 200AL modules
Interfaces
Number of PROFIBUS interfaces
1
1. Interface
Interface types
• RS 485
Yes
• Output current of the interface, max.
90 mA
Protocols
• PROFIBUS DP slave
Yes
RS 485
• Transmission rate, max.
12 Mbit/s
PROFIBUS DP
Services
– SYNC capability
Yes
– FREEZE capability
Yes
– DPV0
Yes
– DPV1
Yes
Isochronous mode
Isochronous operation (application synchro-
nized up to terminal)
No
Interrupts/diagnostics/status information
Status indicator
Yes
Alarms
Yes
Diagnostics function
Yes
Diagnostics indication LED
• RUN LED
Yes; Green LED
• ERROR LED
Yes; Red LED
• MAINT LED
Yes; yellow LED
• Monitoring of the supply voltage (PWR-
LED)
Yes; green PWR LED
• Connection display DP
Yes; Green DP LED
Potential separation

Siemens SIMATIC ET 200SP IM 155-6 DP HF Specifications

General

Product type designation	IM 155-6 DP HF
Manufacturer	Siemens
Series	SIMATIC ET 200SP
Interface	PROFIBUS DP
Protocol	PROFIBUS DP
Power Supply	24 V DC
Number of DP masters	1
DP master	Yes
Isochronous mode	Yes
Integrated web server	Yes
PROFINET IO Device	No
Number of IO controllers	0
IRT	No
MRP	No
MRPD	No
Shared device	No
Rated value (DC)	24 V
Permissible range, upper limit (DC)	28.8 V
Reverse polarity protection	Yes
Protection class	IP20
Mounting	DIN rail
Transmission rate	12 Mbps
Address area	244 bytes
I&M data	Yes
Number of S7 program blocks	0
Number of clock memories	0
Number of counters	0
Number of data blocks	0
Number of timers	0
Operating temperature	60 °C
Storage temperature	-40 °C to +70 °C
Relative humidity	95%
