Technical specifications
7.1 Technical specifications
Interface module IM 155-6 DP HF (6ES7155-6BA01-0CN0)
54 Manual, 10/2018, A5E03916550-AD
Article number
6ES7155-6BA01-0CN0
between backplane bus and electronics
No
between PROFIBUS DP and all other circuit
components
Yes
between supply and all other circuits
No
Permissible potential difference
between different circuits
Safety extra low voltage SELV
Isolation
Isolation tested with
707 V DC (type test)
Ambient conditions
Ambient temperature during operation
• horizontal installation, min.
0 °C
• horizontal installation, max.
60 °C
• vertical installation, min.
0 °C
• vertical installation, max.
50 °C
Altitude during operation relating to sea level
• Installation altitude above sea level, max.
2 000 m; On request: Installation altitudes greater
than 2 000 m
Connection method
ET-Connection
• via BU/BA Send
Yes; + 16 ET 200AL modules
Dimensions
Width
50 mm
Height
117 mm
Depth
74 mm
Weights
Weight, approx.
150 g

Siemens SIMATIC ET 200SP IM 155-6 DP HF Specifications

General

Product type designation	IM 155-6 DP HF
Manufacturer	Siemens
Series	SIMATIC ET 200SP
Interface	PROFIBUS DP
Protocol	PROFIBUS DP
Power Supply	24 V DC
Number of DP masters	1
DP master	Yes
Isochronous mode	Yes
Integrated web server	Yes
PROFINET IO Device	No
Number of IO controllers	0
IRT	No
MRP	No
MRPD	No
Shared device	No
Rated value (DC)	24 V
Permissible range, upper limit (DC)	28.8 V
Reverse polarity protection	Yes
Protection class	IP20
Mounting	DIN rail
Transmission rate	12 Mbps
Address area	244 bytes
I&M data	Yes
Number of S7 program blocks	0
Number of clock memories	0
Number of counters	0
Number of data blocks	0
Number of timers	0
Operating temperature	60 °C
Storage temperature	-40 °C to +70 °C
Relative humidity	95%
